BLX5 Explosion-Proof Limit Switch (Ex d IIC / DIP)
-
Explosion Protection: Ex d IIC T6 Gb / Ex tD A21 IP66 T80°C
-
Suitable for Zone 1, Zone 2, Zone 21 & Zone 22
-
Protection Grade: IP66
-
Anti-corrosion Grade: WF1
Product Overview
The BLX5 Explosion-Proof Limit Switch is designed for safe position detection and control in hazardous industrial environments where explosive gases or combustible dust may be present.
Manufactured with a rugged die-cast aluminum alloy enclosure, this flameproof limit switch ensures reliable operation in harsh conditions such as oil & gas facilities, chemical plants, offshore platforms, and industrial automation systems.
It is suitable for Zone 1 & Zone 2 gas environments and Zone 21 & Zone 22 dust environments, covering explosion gas groups IIA, IIB, and IIC.
Application
-
Oil & gas extraction facilities
-
Chemical and petrochemical plants
-
Offshore platforms and marine installations
-
Pharmaceutical manufacturing lines
-
Industrial automation hazardous areas
-
Conveyor systems and machine safety detection
Technical Parameters
| tem | Specification |
|---|---|
| Explosion Marking | Ex d IIC T6 Gb / Ex tD A21 IP66 T80°C |
| Rated Voltage | AC220V / AC380V |
| Rated Current | 10A |
| Protection Grade | IP65 |
| Anti-corrosion Grade | WF1 |
| Cable Entry | G1/2″ |
| Cable Diameter | Φ6 – Φ12 mm |
| Contact Configuration | 1NO + 1NC |
| Enclosure Material | Die-cast Aluminum Alloy |
| Standards | GB3836 / IEC Explosion Standards |
Features
-
Die-cast aluminum alloy housing with electrostatic powder coating
-
Reliable explosion-proof structure with flexible actuation
-
Multiple actuator types for different industrial applications
-
Supports both cable wiring and steel conduit wiring
-
Stable contact performance with long mechanical life
-
Suitable for outdoor and corrosive environments
Outline & Mounting
Model Designation
Product Selection Table
| Model | Description |
|---|---|
| BLX5-D | Single lever actuator |
| BLX5-L | Roller plunger actuator |
| BLX5-S | Double lever actuator |
| BLX5-Z | Standard plunger actuator |
| BLX5-N | Flexible rod actuator |
| BLX5-K | Adjustable actuator type |
