BAT-M Explosion-Proof Led Floodlight
- Explosion protection: Ex d IIC T3 Gb
- Hazardous area: Zone 1 & Zone 2
- Anti-corrosion grade: WF1
- Protection grade: IP65
- Power range: 50W – 200W
Product Overview
BAT-M Series Explosion-Proof LED Floodlight is designed for hazardous locations with explosive gas atmospheres. It features Ex d e IIC T3 Gb protection and is suitable for Zone 1 and Zone 2 areas, commonly used in oil & gas, chemical,and industrial facilities.
Application
- Zone 1 and Zone 2 hazardous areas with explosive gas atmospheres
- Locations with flammable gases and vapors
- Petroleum, chemical, pharmaceutical, offshore platforms, and other industrial sites
- Areas requiring high-intensity and reliable illumination
- Suitable for AC power supply or DC emergency lighting systems
- Ambient temperature: -20°C to +40°C
Technical Parameters
| Item | Specification |
|---|---|
| Explosion Protection Marking | Ex d e IIC T3 Gb |
| Rated Voltage | AC 90–270V |
| Light Source | LED |
| Luminous Efficacy | ≥ 90 lm/W |
| Power Factor | ≥ 0.9 |
| Color Temperature | 5500 K |
| Color Rendering Index (CRI) | Ra ≥ 70 |
| Ingress Protection (IP) | IP65 |
| Anti-corrosion Grade | WF1 |
| Standards | GB 3836.1 / .2 / .3(Aligned with IEC 60079 series) |
Power & Luminous Flux
| Power (W) | Luminous Flux (lm) |
|---|---|
| 50 | 5000 |
| 60 | 5790 |
| 70 | 6680 |
| 80 | 7530 |
| 100 | 9300 |
| 120 | 12300 |
| 140 | 13900 |
| 150 | 14300 |
| 180 | 16900 |
| 200 | 18500 |
Features
• High-efficiency LED light source with low power consumption and long service life
• Die-cast aluminum housing with excellent heat dissipation for hazardous environments
• Tempered glass cover, impact-resistant and corrosion-resistant
• Professional optical design ensuring uniform light distribution and reduced glare
• Suitable for industrial hazardous areas requiring stable and reliable illumination
• Modular structure for easy installation and maintenance
• Multiple mounting options to meet different site requirements
Outline & Mounting
| Item | Specification |
|---|---|
| Product Type | BAT-M Series Floodlight |
| Mounting Options | Wall-mounted (Bracket) / Street light mounting |
| Cable Entry | G3/4 threaded entry |
| Mounting Diameter | Ø61 mm (street light mounting) |
| Installation Area | Hazardous gas environments |
Installation dimensions and mounting options for the BAT-M explosion-proof LED floodlight
Model Designation
Product Selection Table
| Model | Power (W) | Luminous Flux (lm) |
|---|---|---|
| BAT-M50 | 50 | 5000 |
| BAT-M60 | 60 | 5790 |
| BAT-M70 | 70 | 6680 |
| BAT-M80 | 80 | 7530 |
| BAT-M100 | 100 | 9300 |
| BAT-M120 | 120 | 12300 |
| BAT-M140 | 140 | 13900 |
| BAT-M150 | 150 | 14300 |
| BAT-M180 | 180 | 16900 |
| BAT-M200 | 200 | 18500 |
- Select and specify the explosion-proof marking according to the product model and specifications, for example: if you require a 100W LED explosion-proof floodlight with road-style mounting, the product model would be BAT-M100m ExdeⅡCT3 Gb.
- This luminaire is supplied with a light source.
- Wall mounting is also suitable for base mounting, ceiling mounting, and other installation methods.
- Please specify if there are any other special requirements.
